IWR1642BOOST mmWave Radar PCBA

Original price was: $599.00.Current price is: $499.00.

Manufacturer: Texas Instruments
Product category: RF development tools
RoHS: not available
Product: Evaluation Modules
Type: RF Receiver
Tool used for evaluation: IWR1642
Frequency: 76 GHz to 81 GHz
Trademark: Texas Instruments
Working power supply voltage: 5 V
Product type: RF Development Tools
Series: IWR1642
Subcategory: Development Tools
Trademark name: mmWave
Unit weight: 245.590g

15 in stock


IWR1642BOOST mmWave Radar PCBA
IWR1642 76GHz to 81GHz Single-Chip Millimeter-Wave Sensor Evaluation Module with Integrated DSP and MCU
The IWR1642BOOST is an easy-to-use 77GHz millimeter wave sensor evaluation board for the IWR1642 device that connects directly to the microcontroller (MCU) LaunchPad™ development kit.

The BoosterPack™ includes everything you need to start developing software for the on-chip C67x DSP core and low-power ARM R4F controller, including on-board emulation for programming and debugging, and on-board buttons and LEDs for quick integration of a simple user interface.

The kit comes with millimeter wave tools and software, including mmWave Studio (MMWAVE-STUDIO) and the millimeter wave software development kit (MMWAVE-SDK).

With a 20-pin BoosterPack header as standard, the evaluation board is compatible with a wide range of MCU LaunchPad development kits and simplifies prototyping efforts.

Additional features can be enabled using the add-on board. For example, access to raw sensor data via the LVDS interface is supported.

A 5V, >2.5A power brick with a 2.1mm barrel socket (center positive) is not included. It is recommended that an external power supply be purchased that meets applicable regional safety standards.

On-board antenna for field testing
XDS110-based JTAG emulation via flash-programmed serial port
UART to USB interface for control, configuration and data visualization
LaunchPad interface for seamless connection to MCU
CAN connector supports direct connection to automotive units

mmWave Radar PCBA04
mmWave Radar PCBA
mmWave Radar PCBA05
mmWave Radar PCBA
mmWave Radar PCBA06
mmWave Radar PCBA

Texas Instruments IWR1642BOOST Millimeter Wave Sensor Evaluation Module (EVM) is a simple and easy-to-use evaluation board for IWR1642 millimeter wave sensors that can be directly connected to TI MCU LaunchPad Development kit.

BoosterPack includes the development of software C67x DSP core and low-power ARM All components required for the R4F controller. This evaluation board includes onboard simulation design for programming and debugging, onboard buttons, and LEDs, which can quickly integrate with a simple user interface.

Excluding 5V 2.5A power brick with 2.1mm cylindrical plug (center positive pole). It is recommended to purchase an external power supply that meets the applicable regional safety standards.

The normal transmission power of IWR1642BOOST is usually between 10 and 20 dBm. The maximum transmission power can generally reach around 30 dBm.

The methods to adjust and increase the transmission power of IWR1642 millimeter wave radar include: 1 Adjust RF power setting 2. Use gain antenna or amplifier 3 Adjusting work frequency and bandwidth
